Aluminum Race Haulers


ATC All Aluminum Race Haulers

The ATC Race Haulers are offered with a variety of Packages known as the CH Series. From the CH205 with all the necessities to the CH450 completely loaded with all of the desireable features. The CH Packages are available in both bumper pull and gooseneck models up to 53' long. Add any of the hundreds of options to build the perfect race hauler for you and your team.  Call one of our professionals for assistance and a custom quote. 877-327-0888

Please Note:  Various sizes and colors are available both on hand and at the factory. All factory inventory can be on site within 24 hours. Please contact us for today's available inventory.






  Bumper Pull Race Haulers                 Gooseneck Race Haulers                      Stackers

New Tilt Deck Stacker Lift!

Available Packages:

CH205 SERIES SPECIFICATIONS

FRAME

• FULL PERIMETER ALUMINUM FRAME
• TORSION AXLES WITH EZ LUBE HUBS
• SPREAD AXLE DESIGN WITH FENDERETTES
• ELECTRIC BRAKES - ALL AXLES
• GEL CELL BATTERY BREAKAWAY KIT
• 2-5/16" COUPLER
• SAFETY CHAINS & HOOKS
• 5000# ZINC PLATED MANUAL JACK
• 16" O/C FLOOR CROSSMEMBERS
• 16" O/C ROOF CROSSMEMBERS - 1"x 3"
• 48" BEAVERTAIL
• 16" O/C WALL SUPPORTS

INTERIOR

• ADVANTECH SUB FLOOR
• BLACK COIN TPO FLOORING
• BLACK COIN TPO ON RAMP AND FLAP
• SCREWLESS ALUMINUM WALLS AND CEILING
• 7’ INTERIOR HIEGHT
• 8’ BASE CABINETS - RED
• 8’ OVERHEAD CABINETS - RED
• (3) GFI PROTECTED RECEPTS
• 25’ SHORE CORD
• 30 AMP BREAKER BOX WITH MOTORBASE PLUG
• BRACE AND WIRE FOR FUTURE A/C
• (4) 5000# RECESSED D-RINGS
• ROOF VENT
• L.E.D. INTERIOR LIGHTING

EXTERIOR

• 4" UPPER RUB RAIL TRIM
• 7" LOWER RUB RAIL TRIM
• .030 ALUMINUM
• ALUMINUM WHEELS
• PREP FOR ALUMINUM IN/OUT STEP
•  (1) GFI PROTECTED RECEPT
• POLISHED CAST CORNERS
• ONE-PIECE ALUMINUM ROOF
• 36" SIDE DOOR - 405 SERIES
• STANDARD FLUSH LOCK
• REAR RAMP DOOR WITH CONTINUOUS HINGE
• ALUMINUM BAR LOCKS
• STAINLESS STEEL HASPS
• 7-WAY PLUG
• 24" HIGH ATP STONEGUARD
• L.E.D. CLEARANCE LIGHTS
• L.E.D. SLIM LINE BRAKE LIGHTS

CH305 SERIES SPECIFICATIONS

FRAME

• FULL PERIMETER ALUMINUM FRAME
• TORSION AXLES WITH EZ LUBE HUBS
• SPREAD AXLE DESIGN WITH FENDERETTES
• ELECTRIC BRAKES - ALL AXLES
• GEL CELL BATTERY BREAKAWAY KIT
• 2-5/16" COUPLER
• SAFETY CHAINS & HOOKS
• 5000# ZINC PLATED MANUAL JACK
• 16" O/C FLOOR CROSSMEMBERS
• 16" O/C ROOF CROSSMEMBERS - 1"x 3"
• 48" BEAVERTAIL
• 16" O/C WALL SUPPORTS

INTERIOR

• ADVANTECH SUB FLOOR
• BLACK COIN TPO FLOORING
• BLACK COIN TPO ON RAMP AND FLAP
• SCREWLESS ALUMINUM WALLS AND CEILING
• 7’ INTERIOR HIEGHT
• 8’ BASE CABINETS
• 8’ OVERHEAD CABINETS
• (3) GFI PROTECTED RECEPTS
• 25’ SHORE CORD
• 30 AMP BREAKER BOX WITH MOTORBASE PLUG
• BRACE AND WIRE FOR FUTURE A/C
• (4) 5000# RECESSED D-RINGS
• ROOF VENT
• L.E.D. INTERIOR LIGHTING

EXTERIOR

• 4" UPPER RUB RAIL TRIM
• 7" LOWER RUB RAIL TRIM
• .030 ALUMINUM
• ALUMINUM WHEELS
• ALUMINUM IN/OUT STEP
•  (1) GFI PROTECTED RECEPT
• (2) HIGH OUTPUT LED SCENE LIGHTS WITH (1) WALL SWITCH
• POLISHED CAST CORNERS
• ONE-PIECE ALUMINUM ROOF
• 36" SIDE DOOR - 405 SERIES
• STANDARD FLUSH LOCK
• REAR RAMP DOOR WITH CONTINUOUS HINGE
• STAINLESS STEEL REAR PADDLE LATCHES
• 7-WAY PLUG
• 24" HIGH ATP STONEGUARD
• L.E.D. CLEARANCE LIGHTS
• L.E.D. SLIM LINE BRAKE LIGHTS

CH405 SERIES SPECIFICATIONS

FRAME

• FULL PERIMETER ALUMINUM FRAME
• TORSION AXLES WITH EZ LUBE HUBS
• SPREAD AXLE DESIGN WITH FENDERETTES
• ELECTRIC BRAKES - ALL AXLES
• GEL CELL BATTERY BREAKAWAY KIT
• 12” EXTENDED TONGUE
• 2-5/16" COUPLER
• SAFETY CHAINS & HOOKS
• 5000# ZINC TOP WIND JACK
• 16" O/C FLOOR CROSSMEMBERS
• 16" O/C ROOF CROSSMEMBERS - 1"x 3"
• 48" BEAVERTAIL
• 16" O/C WALL SUPPORTS

INTERIOR

• EXTRUDED ALUMINUM FLOOR
• EXTRUDED ALUMINUM ON RAMP AND FLAP
• SCREWLESS ALUMINUM WALLS AND CEILING W/ 36” CARPET
• INSULATED WALLS AND CEILING
• 7’ INTERIOR HIEGHT
• 8’ L-SHAPE BASE CABINETS
• (2) SINGLE 5" DRAWER UNITS INTEGRATED INTO LOWER CABINET
• ALUMINUM DRESSER CLOSET
• 8’ OVERHEAD CABINETS
• (3) LED PUCK LIGHTS UNDER UPPER CABINETS WITH WALL SWITCH
• IN FLOOR SPARE TIRE COMPARTMENT
• (3) GFI PROTECTED RECEPTS
• 25’ SHORE CORD
• 50 AMP BREAKER BOX WITH MOTORBASE PLUG/60 AMP CONVERTER/12V FUSE PANEL
•  (4) 5000# RECESSED D-RINGS
• LED INTERIOR LIGHTING

EXTERIOR

• 4" UPPER RUB RAIL TRIM
• 7" LOWER RUB RAIL TRIM
• .040 ALUMINUM
• ALUMINUM WHEELS
• ALUMINUM IN/OUT STEP
•  (1) GFI PROTECTED RECEPT
• POLISHED CAST CORNERS
• (2) 12V SURFACE MOUNT EXTERIOR HIGH-OUTPUT LED SCENE LIGHTS WITH WALL SWITCH
• 6" STAINLESS STEEL REAR SPOILER WITH (3) LED LIGHTS & WALL SWITCH
• ONE-PIECE ALUMINUM ROOF
• 36" SIDE DOOR - 405 SERIES
• STANDARD FLUSH LOCK
• REAR RAMP DOOR WITH CONTINUOUS HINGE
• STAINLESS STEEL REAR PADDLE LATCHES
• 7-WAY PLUG
• 24" HIGH ATP STONEGUARD
• LED CLEARANCE LIGHTS
• LED SLIM LINE BRAKE LIGHTS

Please Call For More Information and a Custom Quote. 877-327-0888




Note: All ATC Quest Models Available In Steel Frame.  Please Contact Us Pricing.

Current Inventory & Special Order Models
